The ＭＯＯＮ． Kit

• Updated moon_asm - fixed word wrapping and made it not break on encountering spaces at the start of a line

• Release.

These are pictures. They're basically specially-compressed Windows BMP images. ＭＯＯＮ． has 555 of these. From a cursory glance, there seem to be a total of 77 that appear in-game and have Japanese text that potentially requires translation.

Naturally, they aren't much use in this form, so you need to convert them into BMP images first. A tool is provided in the ＭＯＯＮ． kit for this purpose. Thankfully, you don't need to convert them back into TGFs afterwards (which is good, because I haven't provided a tool for that) because ＭＯＯＮ． will happily accept the BMPs in place of TGFs.

These are ＭＯＯＮ．'s scripts, which contain the vast majority of text in the game, as well as the stuff to drive the use of backgrounds, play the videos, show the sprites, play voices and sound effects etc. The entire game is essentially programmed with these scripts, from the menu to the CG display. ＭＯＯＮ． contains 119 of these.

However, they aren't in a convenient text-based format, unlike the scripts for engines like nscr and krkr. As a result, they need to be disassembled, which I have already done for you - the resultant scripts are in the 'scripts' directory in the ＭＯＯＮ． kit.

Among other things, these SNX files have an annoying file size limitation - of 64 kilobytes. The issue here is that a number of the scripts come very close to meeting this. As English is a naturally more expansive language than Japanese, it's pretty much inevitable that the English-translated SNX files will end up being larger.

I have, however, already solved this for you, because I've split up the six largest scripts (which is the reason I put the scripts in the ZIP file, rather than simply packing the disassembler.) None of the provided scripts will assemble to an SNX file greater than 36kb, which allows for plenty of room for expansion. If you're particularly wordy, though, it may be a good idea to have a look at your assembled SNX files to make sure they don't get too close.

ＭＯＯＮ．'s executable when you install the game is moon.exe. If you try, for example, renaming the exe, the game won't run. Why?

The answer is really very simple - the aforementioned moon and moon.lst files are found using the name of the game executable. For example, if you renamed moon.exe to bunnygirl.exe, the game will look for 'bunnygirl' and 'bunnygirl.lst' files. If those are present, the game will run just fine.

This is really quite convenient from a translation perspective, because it allows us to have two copies of ＭＯＯＮ． - the original and the translation - in the same directory. The tools and instructions provided expect 'moon_eng.exe', so that's what you'll be calling it. In practice, it's probably good to have a backup ＭＯＯＮ． directory anyway, because you'll find that the original has a nice habit of crashing on things like the save/load menu when provided with save files created by the translated ＭＯＯＮ．.

The replacement ＭＯＯＮ． executable provided in the ZIP is called moon_eng.exe.

Without going into it, ＭＯＯＮ． expects Japanese characters of a certain width and height, whereas we'd rather Latin characters that aren't so fat and allow us to fit more than 21 of on a line.

The spacing has been altered in the provided moon_eng.exe, the side effect of which is to make Japanese text all overlapped and nearly unreadable - but that's fine, because it's not going to be used for the viewing of Japanese text anyway.

As mentioned before, ＭＯＯＮ． expects the main archive file to have the same base name as the executable. As the executable for running the translation is 'moon_eng.exe', you'll need to have moon_eng and moon_eng.lst files otherwise ＭＯＯＮ． will not run. Furthermore, these are the archives you'll be dealing with for translation purposes (replacing the images and scripts of).

To create your moon_eng and moon_eng.lst files, you simply need to copy the existing moon and moon.lst files. The provided copy_moon_archive.bat in the kit will do this for you - just run it. It's also useful for later when you want to refresh your moon_eng and moon_eng.lst after they've gotten a bit large; more on that later.

You can now run moon_eng.exe and the game should start up properly. Note that if you actually try to play the game, the Japanese text will be all overlapped and garbled, for reasons explained previously.

Inside the ZIP archive is a directory tgf, containing a file called placeholder.txt. You can navigate into that directory and delete the file now, if you want - it was only included to create the directory.

This directory is used for storing the extracted TGF images - or, more correctly, the converted BMP files.

To extract the BMPs from the moon archive, run moon_extractTGF.exe. This process will use up about 407mb of disk space.

For translating images, what you will probably want to do is create another directory just for translated images, and copy all the BMPs you need to translate into that. You can then edit them and copy them into the patch directory (explained later) when done. There is no need to change the filename.

The scripts directory contains, well, the game scripts, pre-disassembled and split for your convenience. The application moon_asm.exe will assemble every script in that directory, placing the results in the patch directory. Run it. More about the scripts will be explained later.

The application named moon_patch.exe essentially 'patches' the moon_eng/moon_eng.lst archive with the files inside the patch directory. Note that, as before, the patch directory contains a placeholder.txt file which can be deleted. Not deleting it (and patching the game) will result in the placeholder file being added to the game archive. Because it is never referenced, this won't even be noticable, so it doesn't really matter whether you remove it or not.

Actually, the word 'patch' is extremely appropriate for what this tool does - it appends the files inside the patch directory onto the end of the moon_eng archive and updates the references in moon_eng.lst. On one hand, this is an extremely quick operation. On the other, it results in your moon_eng file becoming bigger each time you patch it. To fix this, occasionally rerun the copy_moon_archive.bat batch file to copy from the original archive files again, then run the patcher.

The patch directory will, in the process of a translation, contain both the assembled SNX files and the edited BMP image files.

The disassembled .txt script files are in a very simple, vaguely assembler-inspired format, with one command per line. The scripts are in SHIFT-JIS format, and if you can't read them, it's probably because of your OS locale, text editor or something else.

  # MOON SCRIPT FILE "DAY01.SNX"
  #
  # Comments are lines beginning with a # character

  X_00 000F 0001
  SETSTATUS '　１日目　－－－－－－'
  X_00 0014 0064


  BACKGROUND 'BG001'
  X_24 00
  X_25 06
  TEXT トラックを降ろされたそこは、すでに建物の中だった。
  TEXT どこまでも秘密主義。
  TEXT それでもそれに対し不信感を抱く者など、ここには誰もいないのだ。
  SPRITE 'CGHA01'


Comments are, as shown, lines that begin with a #. Feel free to add comments and blank lines - they won't affect the assembled output at all. Most of the stuff to be translated will be in the 'TEXT' lines - essentially, everything before after 'TEXT' and the space is the line.

Labels are lines that begin with a :, and are used for a couple of the instructions, wherein they begin with a .

If a line isn't blank, and isn't a comment or a label, it's a command. The first word on the line is the command name. Note that a large number of the commands are undocumented - they have no useful name. This is because I haven't really bothered giving all of them names. You generally don't need to know the names of the commands anyway, since you won't be touching the majority of them. Note that the aforementioned TEXT lines are in fact TEXT commands.

It would be a good idea to use the comments to store the original Japanese text, to use as a reference later on. You can also use it to keep notes and stuff. Basically, comment out the line you're about to translate, then type in the translated version of it, as shown:

  X_00 000F 0001
  #SETSTATUS '　１日目　－－－－－－'
  SETSTATUS 'Day 1 -----'
  X_00 0014 0064


  #TEXT トラックを降ろされたそこは、すでに建物の中だった。
  TEXT After being unloaded from the truck, we were already in the building.


Translated text lines are automatically wordwrapped for you (and even split across multiple text blocks if necessary). However, you should take care that there are only ASCII characters in your translated lines - even one non-ASCII character will cause the wordwrapper to ignore that line.

If you want to add a linebreak, type \n. For example:

  TEXT After being unloaded from the truck,\nwe were already in the building.


Note that a linebreak will only work for TEXT commands - it won't make sense in other places. If, for some reason, you want to use the \ character (which will appear like a yen sign in ＭＯＯＮ． anyway), type \\.

SETSTATUS - This is a command that sets the 'status line' which mostly just appears when you save the game - it is used to provide a quick summary of current time and location. Be careful with translating these, and experiment. There's a fairly strict length limit enforced by the limited size of the save/load dialogue display area, and ＭＯＯＮ． is also rather fussy about which characters are allowed and which will cause the game to crash on saving/loading. The / character seems to be one of the latter, as an example.

  #SETSTATUS '　２日目　午前　Ａ棟'
  SETSTATUS 'Day 2, Morning, Building A'


SELECT - This command takes a variable (this is a flag number, but you don't need to worry about it) and a number of strings, corresponding to different options the player can select. These don't seem to have a length limit, but keep them under 40 characters or so, just so they don't cause graphical issues. Note that this, and other text commands other than the TEXT one use ' ' to mark the starts and ends of strings. If you want to use a ' in one of these, precede it with a \. (e.g. \')

  #SELECT 0003 '本当に大丈夫？' '顔色悪いよ？'
  SELECT 0003 'Is she really all right?' 'Doesn\'t she look a bit pale?'


INIT.SNX - the script that is run first. Shows the videos, controls the title screen menu etc. and runs the first 'game' script, DAY01A.SNX (originally DAY01.SNX, but this is one of the scripts I split)

DAY01A.SNX through DAY202.SNX - basically, significant / main events that happen on the day in question. Some days have multiple scripts, but the filename usually make this obvious - for example, day 20 is split across DAY20A, DAY20B and DAY202.

MINMES.SNX - contains the events that happen in the usage of the MINMES machine. This script file contains multiple events, selected through a jump structure at the top.

EL1.SNX through EL8.SNX - similar to MINMES.SNX, contains the ELPOD scenes. The difference is that these scenes are divided up, one event per file.

OMAKE.SNX - contains code for the omake mode stuff, which includes the CG viewer and the BGM recollection

A_D*.SNX, B_D*.SNX, C_D*.SNX, B*.SNX, BOSS.SNX, EM14.SNX, JO_D16.SNX, PR_D16.SNX, UG_D*.SNX, UNGRO.SNX, WC_D*.SNX, X_D*.SNX - the MAPS. You hated them as a ＭＯＯＮ． player; now it's time to hate them as a translator. There are 79 of these, all containing text to translate. With the plain 'moving around' interface stuff, it's fairly standard from map to map, I envisage anyone translating this using software that allows him or her to search+replace multiple files at a time. You'd still need to be quite careful, though, and there's always going to be exceptions. The maps are going to be a pain to translate no matter what. They also contain their own event text stuff, so it's not all interface.

DEAD1.SNX - contains the script for one of ＭＯＯＮ．'s bad endings; the one you get if you're caught being somewhere you shouldn't be.

TEST.SNX, TITLE.SNX, PROLOGUE.SNX, TATIITI.SNX - testing code, stuff that was going to be used but wasn't etc.; all thoroughly uninteresting and irrelevant to a translator.
